J-Etna™ Low-Order EOD Tool

Alford J-Etna positioned against steel plate target
Steel targets after firing by Alford J-Etna
Alford J-Etna positioned against UXO
Alford J-Etna low order EOD tool
Alford J-Etna positioned against steel plate target
Steel targets after firing by Alford J-Etna
Alford J-Etna positioned against UXO
Alford J-Etna low order EOD tool

J-Etna™ is a Project Yellowstone low-order EOD tool for the Humanitarian Mine Action (HMA) community, powered by ALX™ (Alford's Liquid Explosive) binary liquid explosive technology. Neither ALX™ component is classified as an explosive when unmixed, removing the licensing, transport, and storage barriers that constrain conventional explosive supply in post-conflict environments. The two components mix only at the point of deployment. J-Etna's performance mirrors that of the Vulcan™, using the same metal alloy Jet-Forming Cone to induce low-order deflagration through up to 27mm of munition casing.     For a conventional explosive alternative with adjustable NEQ, see Humanitarian Demining Vulcan™.     For programme context, see the Humanitarian Mine Action application page.

Neither component is explosive until mixed. ALX™ ships and stores as two non-explosive liquids, enabling procurement, transport, and storage in countries where conventional explosive supply is restricted or unavailable

Mix only at the point of deployment. No preparation until the task; components arrive pre-measured in easy-to-use containers

Same metal alloy JFC as the Vulcan™, penetrating up to 27mm of munition casing before deflagrating the main filling without detonation

Fixed NEQ of 78g, standardised for repeatable procedure across the mine and ERW types encountered in HMA operations

Fully self-contained kit of ten charges, including ALX™ binary explosive, filling tools, user instructions, and protective gloves and eye protection

Explosive Load and Performance

J-Etna incorporates a metal alloy Jet-Forming Cone (JFC) to induce the low-order destruction of munitions through deflagration. The JFC can penetrate up to 27mm of munition casing material before igniting and deflagrating its main filling.
Unlike the Vulcan, the J-Etna’s body is sealed; therefore, the NEQ is not variable, and the projectile cannot be changed.
ALX components are provided in easy-to-use containers, in low-volume. They are not classified as explosives when unmixed, enabling easy transportation, storage, and loading. The explosively formed metal alloy projectile ignites and deflagrates explosive targets without causing detonation.

Kit Components

Each kit includes:

  • Ten J-Etna charges
  • ALX binary explosive
  • Filling tools
  • User instructions
  • Protective gloves and eye protection

Specifications

NEQ 78g
JFC Metal alloy
Part no. ET2901
